パイオニアPL-360PLL クオーツマニアルレコードプレーヤー中古整備済み実用品


  • Product Quantity
    : 1
  • Starting Bid
    :5,200円
  • Highest Bidder
    : b_t_m / Rating:29
  • Listing Date
    :2025年09月21日 20時30分
  • Bidding closes on
    :2025年09月27日 18時32分
  • Auction Number
    :q1200222055
  • Condition
    :Damaged and stained (specify in description)
  • Automatic Extension
    :Yes
  • Authentication
    :No
  • Early Closing
    :Yes
  • Can I return the product?
    :no
  • Description
  • Q&A ()
  • Cost Estimator
  • Problem Item Response Procedur
Notes
  1. Plug-in electrical appliances are only shipped by air (shipping by sea requires commodity inspection)

The
The

パイオニアPL-360PLL クオーツマニアルレコードプレーヤー中古整備済み実用品

アーム、スイッチ類は可動部分のすべてをクリーニング整備点検を行いました其の為問題なく音楽鑑賞が出来ます、PL-380のオート機構を排除したマニュアルプレーヤーで販売台数が少なかったので中々探すのが難しいプレーヤーです、オート機構が無いのでアームの音質劣化が有りませんのでマニア向け商品でした

出品商品はメカはとても良い状態ですがキャビネットの塗装に荒れが有るため外観を気にする方には不向きな商品です

ダストカバーは実用上問題になるような傷やクモリは有りません

外観は写真で御判断ください

付属品はソニーのVM-26カートリッジにND-132交換針、45アダプター試聴用のレコード3枚です

このカートリッジはOEM製品ですのでND-132の他ヤマハN-5500、サンスイSC-50などが互換使用出来またリーズナブルな価格でヤフオクで手に入れることが出来ます

針圧は2.2が推奨値ですが2gから3g位の範囲で使用出来ます

整備し稼働確認して出荷いたしますが時代を経た中古品ですので保障は有りません

返品もクレームもお受けできませんので出品評価や質問、写真などで慎重にご判断の上ご入札ください古い商品ですので部品の補修、錆止めの塗装などが有りますので廉価で提供いたしますので外観を気になさらない方にはお買い得な商品です

ターンテーブルが重いので箱の下に同梱いたしますので140サイズになります

使用説明書が無いので落札後メインスイッチとスタートスイッチなどの使用方法はお知らせ致しますまた針圧調整などはPL-370と同じですのでPL-370の取説をお付けいたします

機種の説明

パイオニアPL-360

クォーツPLL
DCサーボモーターを採用した前面操作型マニュアルプレイヤー

駆動モーターはハイトルククォーツPLL DCサーボホールモーターで、精度の高い水晶発振子による基準信号を応用し、ターンテーブルの進み遅れを位相差制御し回転ムラ0.025%以下、S/N78dB以上を実現し、回転数偏差も±0.002%以内に抑えられてます。

起動特性は1.3kg・cmのハイトルク設計で、1/3回転以内で定速回転になります

 アームは精巧なスタビリティサポート方式を採用しており、安定度の高いジンバルサポート構造で初動感度7mgを実現メインウェイトを支点に近づることで慣性モーメントを軽減し、トラッカビリティを大幅に向上させています

キャビネットはコアキシャルサスペンション(同軸懸架方式)を採用しモーターとアームをアンダーボードに取り付け、そのアンダーボードをダイキャストキャビネットからスプリングサポートしてフローティングさせた構造を採用していますのでハイパワー再生時にも音圧や振動の影響を受けにくくし、ハウリングマージンを大幅に向上しています

ソフトタッチのスタート・ストップボタンを搭載しています。

オイルダンプ式のアームエレベーションで聴きたいポジションに針を降ろしてスタートボタンを押せば、素早い頭出しが行えます。また、ストップボタン連動の純電子式のブレーキでスピーディなレコード変換が可能です

クォーツロックインジケーターを採用

モーター              クォーツPLLブラシレスホールモーター

駆動方式              ダイレクトドライブ

ターンテーブル    33cmアルミダイキャスト

慣性質量              330kg-cm2

回転数    33・1/3、45rpm

回転ムラ              0.025%以下(WRMS)

S/N        78dB以上(DIN-B)

65dB以上(JIS)

負荷変動              0%(針圧200g以内)

起動特性              1/3回転以内

起動トルク           1.3kg・cm

回転数偏差           0.002%以下

ドリフト              時間ドリフト:0.00008%/h

温度ドリフト:0.00003%/℃

<トーンアーム部>

型式       スタティックバランスS字型パイプアーム

実効長    237mm

オーバーハング    15mm

適合カートリッジ自重       4g~9g

高さ調整範囲       ±3mm

<その他>

付属機構              クイックストップ

針圧直読ウェイト

アーム高さ調整機構

アームエレベーション

アンチスケーティング

フリーストップヒンジ

使用半導体等       水晶x1

ICx3

ホール素子x3

LEDx3

トランジスタx12

ダイオードx5

電源電圧              AC100V、50Hz/60Hz

消費電力              10W

外形寸法              幅456x高さ140x奥行377mm

重量       10.5kg
